Vertical Mixers CMF-1200
Overview:
With 1,200 cu. ft. mixing capacity, this feed mixer can evenly distribute products for the best nutrition.
Features
The 1200 is part of our CMF series of vertical mixers that cut materials like hay, straw, and corn stocks.
They also mix materials like distillers, silage, corn, and more.
Specifications
| WEIGHT | |
|---|---|
| Total | 21,740 lbs (9,961.1 kg) |
| Tongue Weight | 2,300 lbs (1,043.26 kg) |
| TRANSPORT DIMENSIONS | |
| Width | 11' 1/2" (3.37 m) |
| Length | 27' 2 1/4" (8.29 m) |
| Height | 10' 7" (3.23 m) |
| WORKING DIMENSIONS | |
| Loading Height | 10' 7" (3.23 m) |
| Width | Between 11'6 1/2" and 13' Depending on Conveyor |
| CHASSIS FEATURES | |
| Towing Arrangement | V-Block or Clevis Type Hitch |
| Jack Capacity | 7,000 lbs (3,175.2 kg) |
| Jack Travel | 10" (25.4 cm) |
| Tires | |
| Wheels | Four 22.5 x 12.25" |
| Axle | Oscillating |
| Bearings | Tapered Roller |
| Extensions | 12" Rubber (standard) |
| CAPACITIES | |
| Mixing capacity with 12" Extension | 1,200 cu. ft. (33.98 cu. m) |
| Gross Weight Capacity | 55,740 lbs (25,283.24 kg) |
| Tare Weight - TMR | 34,000 lbs (15,422.14 kg) |
| AUGERS | |
| Number | 2 |
| Diameter | 88" (282.52 cm) |
| Flighting Thickness | 5/8" (1.59 cm) |
| Number / Thickness Knives | 18-1/4" (0.635 cm) Self-Sharpening |
| DRIVELINE AND GEAR BOXES | |
| Drive Line | 1 3/4” (4.45 cm) Constant velocity 1,000 RPM PTO shaft With Two-Speed Gear Box |
| Clutch | Two free motion automatic clutches |
| Gearboxes | Two HD Gear Boxes with 2-Year Warranty |
| UNLOADING CONVEYOR | |
| Type | 36" (91.44 cm) Chain With Hydraulic Orbital Motors |
| Discharge Height | 26 5/8" (67.63 cm) to 55" (139.7 cm) |
| Discharge Options | Left, right, both |
| MISCELANEOUS | |
| Door Opening | 24" (60.96 cm) x 42" (106.68 cm) |
| Floor Thickness | 3/4" (1.91 cm) |
| Side Wall Thickness | 1/4" (0.635 cm) with 24" (60.96 cm) 12 Gauge Replaceable Steel Wall Liner |
| Scale | Digi-Star 4-Point Scale with Optional Digi-Star Scale Monitor |
| Observation Windows | 2 |
| REQUIREMENT FOR OPERATION | |
| PTO Horsepower Required | 150 HP minimum |
| PTO Type | 1,000 RPM, 1 3/4" dia PTO Shaft with 20 splines |
| Min. Tractor Hydraulic Output | |
| SMV Sign and Road Lights | Standard Equipment |
| Electrical | 12 VDC (battery included) |
